Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved

    Buy cheap Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved from wholesalers

    Buy cheap Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved from wholesalers
    • Buy cheap Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved from wholesalers
    • Buy cheap Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved from wholesalers
    • Buy cheap Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved from wholesalers

    Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved

    Ask Lasest Price
    Brand Name : LEPOWER(Shenzhen)
    Model Number : LY-L1802
    Certification : CE RHOS UL TUV CB SAA
    Price : $100.00/pcs
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 5000pcs per month
    Delivery Time : 5-7 days
    • Product Details
    • Company Profile

    Optical lens Outdoor LED street light,50W/60W/80W/90W SMD Lamp/CB approved

    L18-100W-300W LED Street Light.

    (3pin/5pin/7pin NEMA SOCKET/DAYLIGHT SENSOR/PHOTOCELL/LORA SYSTEM OPTIONAL)



    Part NumberLY-L1802LY-L1803LY-L1804LY-L1805LY-L1806
    Wattage100W150W200W250W300W
    Lumen Output15000-16000lm22500-24000lm30000-32000lm37500-40000lm45000-48000lm
    Luminous Efficacy150-160lm/W155-160lm/W155-160lm/W155-160lm/W155-160lm/W
    Input Voltage90-305V AC/200-240V AC 50-60Hz
    Beam AngleTypr I/Tpye II/Type III
    CCT2800~6500K
    CRI≥70 or ≥80 or ≥90
    IP & IK RatingIP66&IK10
    Surge protectionLine earth 4KV, Line-line 10KV/20KV available
    Power factor>0.95
    Power efficiency90%90%90%90%
    THD<15%
    Working temperature-40℃~50℃ 20%~90% H.R
    Storage temperature-40℃~85℃ 10%~90% H.R
    Light pole sizeØ60mm
    Housing materialAL6063-T5
    Housing colorBlack or grey
    InsulationClass 2
    OptionsPWM /DALI/1-10V/Timming/Daylight sensor/Nema 7 Pin socket
    Lifespan>50,000Hrs
    N.W.6.7kg8.0kg9.3kg11.0kg12.2kg

    IES test report of LEPOWER street light


    Trading Conditions

    1. Payment term: 30% deposit by T/T or Western union; 70% before delivery.

    2. Delivery time: 10-15 days for 50pcs; 15-25 days for 500pcs.

    3. Samples time: 5 days.

    4. Shipping terms: FOB Shenzhen.

    5. Discounts will be determined by quantity.

    6. Welcome distributors to cooperate together.


    Quality Control

    1. Before the order to be confirmed, we will check the material & colour temperature by sample which should be strictly.

    2. We will be tracing the different phase of production from the beginning.

    3. Every LED lights quality checked & cleaned before packing.

    4. Before delivery clients could send one QC or point the third party to check the quality.

    5. We will try our best to help clients when problem occurred.


    Warranty terms

    1. 3/5 years warranty.

    2. Under the terms of this warranty, if the product have a failure occurs under normal usage within warranty period, We will provide free/rework new products based on the proof-documents

    3. If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instuction, We will provide paid maintance within warranty period.

    4. SAA/CE/RoHS/TUV/UL


    FAQ:

    Q1.Can we make our own label on the sample lights?
    Yes, we can use the label you offer,we can also do OEM & ODM.


    Q2.Our project is on seaside, what if your lights be corrosion by sea water?
    Metal has high corrosion resistance.Besides, we do best on light surface treatment,

    electrostatic spraying and electrophoresis can effectively protect our lights from salt water corrision.


    Q3. I really would like to try a sample first ,is that possible?
    Yes,that's sure. Our MOQ only 1 pieces,easy know each other better via samples, we look on the long term and win-win cooperation.


    Q4. We now have outdoor projects need to do the lighting design,can you help us?
    Sure we can, we are the leader of outdoor high power LED light supplier, our design teams can provide you the best solution.

    And if you have the tech to make design yourself , we can provide the IES files for you.


    Q5.I have a street/high way project,what's your suggestion?

    Please give me the below information:
    A:the wide of the street.
    B:the arrangement and the height of the light poles
    C:the requirement of the illumination.


    Contact us now and get full quotation list.

    We will take you a new better professional lighting.
