High Power LED Flood Light 200W(50W-500W HB06 Series)
The features of 50w-200w led flood light series.
| Part Number | LY-HB0601 | LY-LHB0602 | LY-HB0603 | LY-HB0604 |
| Wattage | 50W | 100W | 150W | 200W |
| Lumen Output | 7500-8000lm | 15000-16000lm | 22500-24000lm | 30000-32000lm |
| Luminous Efficacy | 150-160lm/W | 150-160lm/W | 150-160lm/W | 150-160lm/W |
| Input Voltage | 90-305V AC/200-240V AC 50-60Hz |
| Beam Angle | 25°/45°/60°/90°/150°/145x100° |
| CCT | 2800~6500K |
| CRI | ≥70 or ≥80 |
| IP & IK Rating | IP66&IK10 |
| Surge protection | Line earth 4KV, Line-line 10KV/20KV available |
| Power factor | >0.95 |
| Power efficiency | 88% | 92% | 92% | 92% |
| THD | <15% or <20% |
| Working temperature | -40℃~50℃ 20%~90% H.R |
| Storage temperature | -40℃~85℃ 10%~90% H.R |
| Housing material | AL6063-T5 |
| Housing color | Black |
| Insulation | Class 2 |
| Options | PWM /DALI/1-10V/0-5V/Timming/ |
| Lifespan | >50,000Hrs |
| Lamp size | 260*105*195mm | 260*168*195mm | 260*258*195mm | 348*260*195mm |
| Packing | 4pcs/CTN 450*280*215mm | 3pcs/CTN 600*310*255mm | 2pcs/CTN 585*310*255mm | 1pcs/CTN 400*310*255mm |
| N.W. | 2.5kg | 3.0kg | 4.0kg | 5.0kg |
The features of 250w-500w led flood light series.
| Wattage | LY-HB0605 | LY-HB0606 | LY-HB0608 | LY-HB0610 |
| Lumen Output | 250W | 300W | 400W | 500W |
| Luminous Efficacy | 37500-40000lm | 45000-48000lm | 60000-64000lm | 75000-78000lm |
| Input Voltage | 150-160lm/W | 150-160lm/W | 150-160lm/W | 150-160lm/W |
| Beam Angle | 25°/45°/60°/90°/150°/145x100° |
| CCT | 2800~6500K |
| CRI | ≥70 or ≥80 |
| IP & IK Rating | IP66&IK10 |
| Surge protection | Line earth 4KV, Line-line 10KV/20KV available |
| Power factor | >0.95 |
| Power efficiency | 92% | 92% | 92% | 92% |
| THD | <15% or <20% |
| Working temperature | -40℃~50℃ 20%~90% H.R |
| Storage temperature | -40℃~85℃ 10%~90% H.R |
| Housing material | AL6063-T5 |
| Housing color | Black |
| Insulation | Class 2 |
| Options | PWM /DALI/1-10V/0-5V/Timming/ |
| Lifespan | >50,000Hrs |
| Lamp size | 438*260*195mm | 520*258*195mm | 520*348*195mm | 520*438*195mm |
| Packing | 1pcs/CTN 490*310*255mm | 1pcs/CTN 570*310*255mm | 1pcs/CTN 570*400*260mm | 1pcs/CTN 570*490*255mm |
| N.W. | 6.0kg | 9.0kg | 11kg | 13kg |
Application of LED Flood Light
1.Industrial halls light, food industry light and warehouses light
2.Exhibition halls light,Showrooms light and retail environments
light
3.Large commercial properties light,Warehouses light
4.Indoor & outdoor arenas light
5.Other large areas that require uniform, high intensity light, as
area light.
6.Airport light,Car selling light,Cooling system light,Cold Storage
light
RFQ
Q1. Can we make our own label on the sample lights?
A: Yes, we can use the label you offer,we can also do OEM & ODM.
Q2. Our project is on seaside, what if your lights be corrosion by
sea water?
A: Aluminium alloy has high corrosion resistance.Besides, we do
best on light surface treatment, electrostatic spraying and
electrophoresis can effectively protect our lights from salt water
corrision.
Q3. I really would like to try a sample first ,is that possible ?
A: Yes,that's sure . It is easy know each other via samples, we
look on the long term and win-win cooperation.
Q4. We now have football stadium projects need to do the lighting
design,can you help us?
A: Sure we can, we are the leader of outdoor high power LED flood
lights and LED design provider, our design teams can provide you
the best solution. And if you have the tech to make design by
yourself , we can provide the IES files for you.
Q5.I have a football/tennis stadium ,what's your suggestion ?
A: please give me the below information:
1) the area of the field
2) the loction and the height of the light poles
3) the requirement of the illumination/lux.
