200 Watt LED Street Light 30000lm Outdoor Public Lighting Fixture With Meanwell Driver

Product attribute sheet

	Model	LY-L1304
	Power	200W
	Input Voltage	AC 200-240V 50/60Hz
	CCT	3000K / 4000K / 5000K
	CRI	Ra>70
	Luminous Efficiency (system effieiency)	150-160lm/w
	Flux of Lamp	30000-32000lm

Product Technology list

• Body material: Aluminum
• Chip brand: Bridgelux / San'an
• Led quantity: 112pcs
• Driver: Meanwell ELG
• Power efficacy: 92%
• PF>0.95
• THD<20%
• Beam angle: 150*70 degree

• Lifetime: >50,000 Hours

• Pole diameter: φ60mm

• IP rating: IP66

• Warranty: 5 years

Product Feature

1. High lumen output. The original lumen of LED is 200lm/w,the lumen output of complete lamp is 150-160lm/w,It can save more energy (60%-70%) than normal led lamps and traditional lamps.
2. Honeycomb briquette effect heat dissipation principle, best thermal management system;
3. Adoption Lepower exclusive light source and ZAG Lens.Compared with similar products,the luminous efficiency can be rised 8% and light transmittance up to 98%.
4. Standard color temperatures: 3000K, 4000K, 5000K, 5700K;
5. Aluminum housing;Minimum 70 CRI;
6. Green product,no UV or IR radiation, no mercury pollution.
7. 5 years limited warranty.

How to install it?

1. Connect the wires to the AC wire,Make sure that Yellow-green ground wire grounding reliably.
2. Remove the screws of back cover,open the back and remove the back cover.

3. Through the poles into the adapter,tighten the screws firmly on the lamp poles.

4. Put the back cover back and tighten the screws.

Packing information

Why choose us--Lepower?

Shenzhen Lepower Opto Electronics Corp., Ltd, founded in 2008, is a professional led product manufacturer since 2008.

1. about 400 staffs, more than 16,000 square meters modern production plant and ten thousand-grade static dust-free workshop.
2. strong independent R & D and innovation capability
3. advanced equipment.
That means we can provide you high quality products and delivery on time.

Our products include: led module, led high bay light,led street light and so on.They have been sold all over the world,and are enjoying great reputation with its professional quality.

If you are looking for LED supplier with high reliability, good quality, reasonable price and full series products which can satisfy your various demands, Lepower, a total solution provider, is definitely your first choice!

Shenzhen Lepower Opto Electronics Corp., Ltd

(Abbreviation"Lepower Corp", stock code:838452 )founded in 2008, is a professional comprehensive LED lighting enterprise engaged in high power led encapsulation, optic design and LED lamp development, has honored as China national high-tech enterprise, Chinese AAA-class Credit firm and listed in TOP 100 Companies in China LED Lighting application industry.

Lepower Corp,with more than 16,000 square meters modern production plant and ten thousand-grade static dust-free workshop, is one of the few companies which own strong independent R & D and innovation capability in China’s LED industry.Lepower Corp has got several national patents and more than 30 utility model patents, is able to offer customers professional LED lighting solutions.

Lepower Corp branded products, including high power led light source,Calculus optic lens, LED modules and special outdoor LED lamps, have been sold all over the world, and are enjoying great reputation with its professional quality. Lepower Corp strictly carry out ISO9001:2008 quality management system, most products have passed several tests by authorized Lab, and got CE, ROHS, LM-80,LM-79, CQC, TUV GS, UL,SAA,CB and C-tick certification. Lepower Corp is a lsoa member of ZHAGA Union.

Our Main Products Line(all reach 160lm/w):
1. LED Modules: 30W 40W 50W 60W
2. LED Street Light: 30W-300W
3. LED Flood Light: 50W-1200W
4. LED High Bay Light:
